Crono 70-80-90-100

Crono Stage III B

70 - 80 - 90 - 100
More power, more performance

The new Crono range offers a total of 6 models, including two 2WD variants. All models feature state of the art FARMotion engines available with 4 power outputs from 65 to 97 HP, to accentuate the already outstanding agility of these machines. Both the tractor and trailer brake systems are also new, and are already compliant with the latest safety regulations.

Design

Incomparable style and attention to detail. An unbeatable combination.
Read more   +

Engine

FARMotion Stage III B engines: impressive performance and extraordinary fuel efficiency.
Read more   +

Transmission

Robust, efficient transmissions with so much choice for configuration.
Read more   +

Hydraulic system

A potent, precise lift. Incredibly smooth steering action.
Read more   +

Cab

A comfortable, functional driver zone with simple controls.
Read more   +

Technical sheetExpandCollapse

70 80 90 100
Maximum power (hp/kW)65/48 75/55,4 88/65 97/71
Homologated power (2000/25/EC) at rated engine speed (hp/kW)65/48 75/55.4 84/61.6 92/67.3
Maximum torque (Nm)292 342 354 369
Cylinders / displacement (n°/cc)3/2887 3/2887 3/2887 3/2887
Lifting capacity (kg)2500 (std)-3500(opt)2500 (std)-3500(opt)2500 (std)-3500(opt)2500 (std)-3500(opt)
Minimum width (mm)1782 1840 1823 2005
Weight with cab (kg)2RM/4RM: 2800 / 3000 2800 / 3000 3000 3000

TechnologiesExpandCollapse

ELECTRONIC ENGINE GOVERNOR

The system uses sensors to monitor a set of engine parameters, and optimises engine function by adjusting injection accordingly. Different engine speeds can also be set and recalled simply from a dedicated button.

DOC

Diesel Oxidation Catalyst. Oxidation catalyst which reduces nitrogen oxide (NOx) and hydrocarbon (HC) emissions produced by combustion. By using the DOC in combination with EGR, these engines attain compliance with Tier 4i regulations

ALL-WHEEL BRAKES

Integral all-round braking system consisting of multiple wet disc brakes integrated in the front and rear axles. Excellent safety even when working on steep gradients.
