Spark 120 - 130 -140

Spark-Spark VRT

120 - 130 - 140
Even more power, technology and style.

The new Spark range is extremely versatile and highly efficient in all working conditions, but the ace up their sleeve setting them apart from the competition is their innate style, with an elegant design without par. With even more power and performance than ever, the new 120, 130 and 140 models are equipped with a state of the art energy saving hydraulic system, boast unrivalled levels of comfort and offer a extensive choice of configurations and accessories, including the highly advanced Agrosky automatic satellite guidance system.

Design

Incomparable elegance.
Read more   +

Engine

New SDF FARMotion engines: born for farming.
Read more   +

Transmission

Superior productivity, sturdy construction and a huge choice of configurations.
Read more   +

Hydraulic system

Efficient, potent performance.
Read more   +

Cab

Uncompromised safety and comfort.
Read more   +

Agrosky

Designed for satellite monitoring of tractors and equipment.
Read more   +

ISOBUS

Systems certified for maximum compatibility with all equipment.
Read more   +

iMonitor 2

iMonitor 2 is the central control unit which enables the management of all Precision Farming applications.
Read more   +

Technical sheetExpandCollapse

120 130 140 120 VRT 130 VRT 140 VRT
Maximum power (hp/kW)116/85 126/93 136/100 116/85 126/93 136/100
Homologated power (2000/25/EC) at rated engine speed (hp/kW)110/80.6 120/88.2 129/94.9 110/80.6 120/88.2 129/94.9
Maximum torque (Nm)462 506 544 462 506 544
Cylinders / displacement (n°/cc)4/3.849 4/3.849 4/3.849 4/3.849 4/3.849 4/3.849
Lifting capacity (kg)5.000 5.000 - 5.000 5.000 -
Minimum width (mm)2.063 2.147 2.147 2.063 2.147 2.147
Weight with cab (kg)5.300 5.600 5.600 5.500 5.800 5.800

TechnologiesExpandCollapse

EGR

Exhaust Gas Recirculation. Exhaust gas recirculation: includes a specific radiator for cooling recirculated exhaust gases, which would otherwise compromise combustion efficiency and increase consumption.

ELECTRONIC ENGINE GOVERNOR

The system uses sensors to monitor a set of engine parameters, and optimises engine function by adjusting injection accordingly. Different engine speeds can also be set and recalled simply from a dedicated button.

ASM

An electronic system which automatically engages and disengages drive to the front wheels and the differential locks in relation to steering angle and speed.

ENERGY SAVING

A system integrated in the hydraulic system which reduces thermal losses, improves efficiency and recovers energy that would otherwise be wasted. When the lift and distributors are not in use, a specific solenoid valve returns the hydraulic fluid flow directly to the transmission housing.

Sense Clutch

Hydraulic reverse shuttle with two multiplate wet clutches (one clutch pack for each direction) and an electronic control unit. Efficient, robust, reliable and flexible.

Stop & Go

A system maximising the potential of the Sense Clutch power shuttle for superlative manoeuvrability. The driver can temporarily stop the tractor using the brake pedals alone.

Damping Control

The adaptive suspension management function is controlled with a simple press of a button. This function of the electronic control system adjusts the suspension shock absorbers in real time, setting a softer or harder damping action according to operating conditions. The result is a ride control system that eliminates vibration, making work safer and more comfortable.
